What is the spectral range of silicon transmission?

crystran.co.uk
Si is a high refractive index material (3.4 @ 8 microns) with very broad spectral transmission in the mid-IR and far-IR regions of the spectrum. However, this broad spectral transmission is not contiguous and Si has very strong absorption in the mid-IR due to impurities; interstitial oxygen at 1107 cm -1, and substitutional carbon at 605 cm -1.

What are the different grades of silicon used in transmission lines?

  • Silicon. But in fact the material may be used in much broader operating range - from 1.2 µm to 1000 µm or even higher. Three grades of silicon are produced to optimize transmission in the operation wavelength region: Optical Czochralski Silicon (OCz-Si), Float Zone Silicon (FZ-Si), and High Resistivity Float Zone Silicon (HRFZ-Si).

What is the difference between IR materials and visible materials?

  • IR materials are usually opaque in the visible while visible materials are usually opaque in the IR; in other words, they exhibit nearly 0% transmission in those wavelength regions. For example, consider silicon, which transmits IR but not visible light (Figure 2). Figure 2: Uncoated Silicon Transmission Curve

What is the difference between NIR and Mir transmission spectra?

  • In Fig.1 transmission spectra in NIR (Near Infrared) and MIR ranges are shown. One can see that in 3 to 5 µm range practically there is no difference in transmission of materials of all used grades and resistances. Also, all grades have phonon absorption peaks stipulated by lattice absorption in the 6.5 to 25 µm range.

What is the transmission range of sisilicon(Si)?What is the transmission range of sisilicon(Si)?

Silicon (Si) Transmission Range : 1.2 to 15 μm (1) Refractive Index : 3.4223 @ 5 μm (1) (2) Reflection Loss : 46.2% at 5 μm (2 surfaces) Absorption Coefficient : 0.01 cm -1 at 3 μm Reststrahlen Peak : n/a 18 more rows ...

image-What is the spectral range of silicon transmission?
image-What is the spectral range of silicon transmission?
Related

What is the spectral range of silicon transmission?What is the spectral range of silicon transmission?

Silicon transmission in the 1 - 25 µm spectral range. Arrows point to the Oxygen absorption peaks. Sample thickness is 5 mm. Lattice absorption, as well as Oxygen absorption, depends on the optical pass of radiation inside the element (roughly on element thickness). It does not depend on resistance.

Related

What are the different grades of silicon used in transmission lines?What are the different grades of silicon used in transmission lines?

Silicon. But in fact the material may be used in much broader operating range - from 1.2 µm to 1000 µm or even higher. Three grades of silicon are produced to optimize transmission in the operation wavelength region: Optical Czochralski Silicon (OCz-Si), Float Zone Silicon (FZ-Si), and High Resistivity Float Zone Silicon (HRFZ-Si).

Related

What is Si silicon used for?What is Si silicon used for?

Silicon (Si) Silicon is used as an optical window primarily in the 3 to 5 micron band and as a substrate for production of optical filters.
