What is the nrnr frame structure?

What is the frame structure of 5G NR?

  • 5G NR frame Structure A frame has duration of 10 ms which consists of 10 subframes having 1ms duration each similar to LTE technology. Each subfame can have 2 μ slots. Each slot typically consists of 14 OFDM symbols.

What is the Subframe length of NR?

  • In the time domain, the subframe length of NR is 1 ms, which is composed of 14 OFDM symbols using 15 kHz subcarrier spacing and normal CP. A subframe is composed of an integer number of slots, and each slot consists of 14 OFDM symbols.

What are the key design principles of NR?

  • The NR frame structure follows three key design principles to enhance forward compatibility and reduce interactions between different functionalities. The first principle is that transmissions are self-contained. Data in a slot and in a beam is decodable on its own without dependency on other slots and beams.
