What is the function of the current sensor?

What are the applications of induction current sensor?

  • Motor Monitoring and Control. One of the most common applications for induction current sensing is motor monitoring. Because current draw is such an excellent indicator of motor condition, the current sensor can be used to solve a wide range of process control, safety, and maintenance problems.

How do you build a current sensor circuit?

  • And we can build a current sensor circuit, simply by exploiting ohm's law. Ohm's law states that, I= V/R, where I is the current, V is the voltage, and R is the resistance. Say, we want to detect 5mA of current. We want 10mA to be the threshold. Any current 10mA or higher will trigger on the output of the circuit.

Which DC current sensor is used in this project?

  • The DC current sensor used in this project is an INA219 High Side DC Current Sensor Breakout and the Hall Effect sensor used is an ACS712 Low Current Sensor Board. Arduino Uno 1 To process the signals from the sensors

image-What is the function of the current sensor?
image-What is the function of the current sensor?
