What is a borescope inspection on aircraft engine?

What is borescope inspection?

A borescope (occasionally called a boroscope, though this spelling is nonstandard) is an optical instrument designed to assist visual inspection of narrow, difficult-to-reach cavities, consisting of a rigid or flexible tube with an eyepiece or display on one end, an objective lens or camera on the other, linked ...

What is an aircraft borescope?

Borescopes are used to inspect airplane engines, brakes, inside wings, behind instrument panel to see areas normally hard to access without taking apart equipment. The most borescopes we listed here are articulating scopes, which means end users can change probe camera's directions easily.

What is borescope inspection in gas turbine?

Gas Turbine Borescope Inspection. ... Borescope inspection of gas turbine can help view and access impossible or hard to reach areas. Gas turbines operate at the extremely high temperatures, hence professional assistance is necessary for safe NDT (Nondestructive Testing) and RVI (Remote Visual Inspection).

What is the purpose of a borescope?

A borescope is an optical tool used to view areas that would otherwise not be visible. A borescope is inserted into the item being evaluated without destroying the item of interest. Light Source to illuminate the target under inspection.Jul 4, 2017

image-What is a borescope inspection on aircraft engine?
image-What is a borescope inspection on aircraft engine?
Related

What is difference between borescope and endoscope?

In short, an endoscope is a type of borescope. While borescopes are mostly used to inspect mechanical objects, endoscopes are better suited to examine a living body. If you work in an industry such as plumbing or mechanics, where you'll need to inspect pipes or mechanical objects, borescopes are the better choice.Mar 5, 2021

Related

What is the difference between borescope and fiberscope?

Most borescopes are fitted with high-definition cameras that allow aircraft maintenance crew to inspect all the small components of an aircraft engine. In contrast, fiberscope lenses cannot capture high quality images. The quality of images taken with a fiberscope is similar to images taken from a night vision camera.Jul 6, 2020

Related

How many types of borescope are there?

As explained above, there are three main types of borescopes: rigid, semi-rigid, and flexible units. Rigid borescopes that consist of a straight tube provide high-quality views.Apr 1, 2020

Related

How much is a borescope?

The fact is that there is no single (or right) response to the question about the price of a borescope because the answer depends on many different factors. These devices range from as little as $100 to upwards of $60 000 and come in an extensive range of sizes and capabilities to meet differing needs.May 9, 2020

Related

Who invented borescope?

Optical physicist Brian O'Brien and fellow physicist Narinder Kapany are known for inventing the first borescope in 1960. Their device used a rigid tube and an optical visual inspection system.Apr 7, 2019

Related

What is depth of field in borescope?

With regards to a borescope, fiberscope, videoscope or pipe camera the depth of field or focal distance is the distance, measured from the objective tip of the instrument at which a usable image is available. Typically, expressed with a minimum and a maximum distance, i.e. 3 to 9mm.Feb 5, 2014

Related

What is engine borescope?

  • Definition of borescope. : an optical device (such as a prism or optical fiber) used to inspect an inaccessible space (such as an engine cylinder)

Related

What is an industrial borescope used for?

  • Industrial borescopes are used to perform remote visual inspections (RVI) when a naked human eye is insufficient for checking out an inaccessible area. Borescopes are used in a wide range of applications, including power generation, automotive, sanitation, aerospace, aviation, metal casting, weaponry, and automotive production.

Related

What is automotive borescope?

  • In automobile production and maintenance, the automotive borescope, is mainly used for testing and diagnosing the wear, coke and blockage of automobile engines, hydraulic components, fuel pipes, cylinders, engines, air conditioning systems, water tanks, differentials, fuel tanks and gearboxes And so on.
