How does a piezoelectric force sensor work?

How does a piezoelectric disk generate a voltage?

  • A piezoelectric disk generates a voltage when deformed (change in shape is greatly exaggerated) A piezoelectric sensor is a device that uses the piezoelectric effect, to measure changes in pressure, acceleration, temperature, strain, or force by converting them to an electrical charge.

What is the difference between quartz and piezoelectric sensors?

  • While quartz sensors must be cooled during measurements at temperatures above 300 °C, special types of crystals like GaPO4 gallium phosphate show no twin formation up to the melting point of the material itself. However, it is not true that piezoelectric sensors can only be used for very fast processes or at ambient conditions.

What is a piezoelectric gyroscope and how does it work?

  • A piezoelectric gyroscope also belongs to this kind of sensor. It is an angular velocity sensor, which is used in navigation systems for automobiles, and a vibration compensation system of a camcorder. It has both a wave generating part and a wave receiving part.

image-How does a piezoelectric force sensor work?
image-How does a piezoelectric force sensor work?
